TEL Tokyo Electron 5087-400391-12 ARM-R COT Scan Assembly Perforated Lithius

TEL Tokyo Electron 5087-400391-12 ARM-R COT Scan Assembly Perforated Lithius

TEL Tokyo Electron 5087-400391-12 ARM-R COT Scan Assembly Perforated Lithius

Inventory # A-18745

  • Part No: 5087-400391-12
  • Model No: SCAN ASSY
  • ARM-R
  • COT Coat Process Station
  • Removed from a TEL Tokyo Electron Clean Track Lithius System

    Installed Components

  • Sanyo Denki Stepping Motor Part No: 103H7851-70E1, StepSyn
  • SMC Linear Actuator Part No: LG-96A-A1

    Parts List (approximation, parts may vary)

    Assembly Part No: 5087-400391-12 SCAN ASSY

  • 5024-000118-11 ACTUATOR LG-96A-A1 1
  • 028-001387-1 FITTING,TUBE EUC4-TR 2
  • 020-000083-1 CAP SCREW M6*12 SUS304 8
  • 020-000028-1 CAP SCREW M4*6 SUS304 2
  • 5086-403395-12 ARM,COT #01 1

    Assembly Part No: 5085-404660-11 HOLDER ASSY,TUBE

  • 5004-300008-11 HOLDER,TUBE (509510036411 1
  • 020-000005-1 CAP SCREW M3*6 SUS304 2

    This TEL Tokyo Electron 5087-400391-12 ARM-R COT Scan Assembly is used working surplus. The physical condition is good, but there are signs of previous use and handling.

    • Sale Details

    • Item Condition: Used Working, 90 Day Warranty
    • Estimated Packed Shipping Dimensions: L x W x H = 36"x24"x14" @ 45 lbs.
    • Only items pictured are included: If a part is not pictured, or mentioned above, then it is not included in the sale. Pictured test equipment is not included or available for sale.
    • For items with multiple quantities: The pictured item is not necessarily the one that will be sent. Serial numbers or country of manufacture may vary.
    • Items are sold with a 90-Day Satisfaction Guarantee

      Lister 31


    Listed with ExportYourStore.com
    $39,966.30

    Original: $133,221.00

    -70%
    TEL Tokyo Electron 5087-400391-12 ARM-R COT Scan Assembly Perforated Lithius—

    $133,221.00

    $39,966.30
    Product image 1
    Product image 2
    Product image 3
    Product image 4
    Product image 5
    Product image 6
    Product image 7
    Product image 8
    Product image 9
    Product image 10
    Product image 11
    Product image 12

    Description

    TEL Tokyo Electron 5087-400391-12 ARM-R COT Scan Assembly Perforated Lithius

    Inventory # A-18745

  • Part No: 5087-400391-12
  • Model No: SCAN ASSY
  • ARM-R
  • COT Coat Process Station
  • Removed from a TEL Tokyo Electron Clean Track Lithius System

    Installed Components

  • Sanyo Denki Stepping Motor Part No: 103H7851-70E1, StepSyn
  • SMC Linear Actuator Part No: LG-96A-A1

    Parts List (approximation, parts may vary)

    Assembly Part No: 5087-400391-12 SCAN ASSY

  • 5024-000118-11 ACTUATOR LG-96A-A1 1
  • 028-001387-1 FITTING,TUBE EUC4-TR 2
  • 020-000083-1 CAP SCREW M6*12 SUS304 8
  • 020-000028-1 CAP SCREW M4*6 SUS304 2
  • 5086-403395-12 ARM,COT #01 1

    Assembly Part No: 5085-404660-11 HOLDER ASSY,TUBE

  • 5004-300008-11 HOLDER,TUBE (509510036411 1
  • 020-000005-1 CAP SCREW M3*6 SUS304 2

    This TEL Tokyo Electron 5087-400391-12 ARM-R COT Scan Assembly is used working surplus. The physical condition is good, but there are signs of previous use and handling.

    • Sale Details

    • Item Condition: Used Working, 90 Day Warranty
    • Estimated Packed Shipping Dimensions: L x W x H = 36"x24"x14" @ 45 lbs.
    • Only items pictured are included: If a part is not pictured, or mentioned above, then it is not included in the sale. Pictured test equipment is not included or available for sale.
    • For items with multiple quantities: The pictured item is not necessarily the one that will be sent. Serial numbers or country of manufacture may vary.
    • Items are sold with a 90-Day Satisfaction Guarantee

      Lister 31


    Listed with ExportYourStore.com
